We introduce you BlackBox 3d printer

BlackBox 3D Printer

What makes us stand out from the crowd?

Filament runout sensor

One of the most annoying things during the long printing process is running out of material. To meet the problem, the "BlackBox" 3d printer has equipped with filament run out sensor. When a problem occurs, sensor will stop printing process until the user will replace the old spool on a new one.

Auto leveling

Proper leveling of the build plate in the printing process has diametric impact on terms of proper adhesion 3d print to it surface. Manual leveling of the build plate can be difficult and time consuming. The auto-leveling feature significantly simplifies this process.

Large build volume

The build plate of dimensions 250 x 200 x 190 mm (9.84 x 7.88 x 7.48 in) provides considerable comfort when printed large or several items at once.

Heated bed platform

The main advantage of the heated build plate is to improve the quality of printed objects. Thanks to that, the contraction of the material takes place in a more controlled manner, the printout doesn't warp and stick better to the surface. This is particularly important when printing of ABS material.

Rigid frame

The frame of "BlackBox" 3d printer is made entirely of aluminum. The outer casing made of a material HIPS provides additional reinforcement. The printer is designed in such a way that the individual mechanical components contribute to the stiffening of the whole structure.

Non-proprietary filament

We believe that 3D printer users, should be free to choose the filament from which they want to print, which is why we tried to design the printer so it gave this possibility. We approach liberally to the choice of material, allowing the user to test and use any commercially available filament.

Technical details

Dimensions

  • Product Dimensions Without Spool

    470 x 459 x 404 mm (L, W, H)
    [18.5 x 18.07 x 15.9 in]

  • Product Dimensions With Spool

    575 x 459 x 404 mm (L, W, H)
    [22.63 x 18.07 x 15.9 in]

  • Product Weight

    ~17 kg [~37.5 lbs]

Mechanical

  • Frame

    Aluminum, HIPS & Plexi Panels

  • Housing

    Partially Enclosed

  • Build Surface

    Ceramic Glass [max temp. 800°C]

  • Linear Motion

    Linear Bearings

  • Stepper Motors

    1.8° Step Angle with 1/16 Micro-Stepping

Electrical

  • Power Input

    AC 110-220V, 50-60 Hz

  • Power Output

    DC 12V, 20A

  • Connectivity

    USB, SD Card

Printing

  • Print Technology

    Fused Filament Fabrication (FFF)

  • Build Volume

    250 x 200 x 190 mm (L, W, H)
    [9.84 x 7.87 x 7.48 in]

  • Layer Resolution

    50 - 400 microns (0,05 - 0,4 mm)
    [0.0019 - 0.0157 in]

  • Nozzle Diameter

    0.4 mm [0.015 in]

  • Filament Diameter

    1.75 mm [0.069 in]

  • Material

    ABS, PLA

  • Heated Platform Max Temp.

    --

  • Hot-End Max Temp.

    300°C

  • Number Of Extruders

    1

Software

  • Open Source Software

    Sic3r, Cura, Repetier-Host

Want to know more? Write to us
